High Pressure Fixed Washer QX-150C,100C

QX-150C type high-pressure cleaning machine The product is my company's own research and development of ultra-high pressure cleaning machine. The cleaning machine is equipped with a motor and a diesel engine according to customer requirements. Suitable for large and small diameter pipe cleaning, heat exchanger, condenser, chemical cleaning, ship cleaning, oil Field cleaning, cleaning of buildings and other workpieces.

Keywords:

Classification:

Scavenging pump for pipes and radiators

wechat

E-mail:

Introduce

QX-150C type high-pressure cleaning machine The product is my company's own research and development of ultra-high pressure cleaning machine. The cleaning machine is equipped with a motor and a diesel engine according to customer requirements. Suitable for large and small diameter pipe cleaning, heat exchanger, condenser, chemical cleaning, ship cleaning, oil
Field cleaning, cleaning of buildings and other workpieces.

The power end of this product is bearing type transmission (between crankshaft and connecting rod). Splash lubrication is adopted as the lubrication method, because the motor power is large, the power end adopts water interlayer to cool the oil temperature, and the packing box also adopts water cooling. The cooling water is connected with the inlet pipe to ensure the cooling effect, and this method can be operated continuously for 24 hours. The hydraulic end of this product is equipped with a safety valve, throttle valve, self-contained system, adjustable throttle valve to adapt to different flow requirements.

This product has the following characteristics:

• Single gun, multi-gun use, pressure difference range is small.

• The use of cut-off type spray gun is safe and convenient to use, which can ensure that the reciprocating pump is in a low pressure (no load) state.

• Stable pressure, low noise, easy to operate, easy to maintain.

• This product is equipped with high pressure hose, spray gun, common nozzle.

Performance parameter table

Maximum speed of diesel engine		1500r/min	Plunger stroke	84mm
theoretical flow		Diesel engine power (kW)			Plunger Diameter mm
theoretical flow		132	185	220
M³/h	L/min	Rated discharge pressure (MPa)
4.2	70	80	95	110	φ30
2.4	40	150	//	//	φ22
