High pressure water injection pump 3S-2.8

3S-2.8 plunger pump can be used as a high-pressure water power source. Used for large and small diameter pipe cleaning, ship cleaning, workpiece cleaning, rust removal, water assisted piling, water corrosion cutting and other purposes, can transport water, emulsion and chemical properties similar to water liquid.

Keywords:

Classification:

High-pressure water-injection pump

wechat

E-mail:

Introduce

The hydraulic end of the pump is equipped with a safety valve, throttle valve, self-contained system, adjustable throttle valve to adapt to different flow requirements. The power end of the pump is a bearing type transmission (between the crankshaft and the connecting rod). The lubrication method adopts splash lubrication, which can run continuously for 24 hours without cooling. For users to support a variety of cleaning machines, valves, high-pressure pipes, spray guns and so on. According to user needs, equipped with a variety of power sources.

Performance parameter table

Maximum motor speed		1470r/min		Plunger stroke	40mm
theoretical flow		Motor power (kW)				Plunger Diameter mm
theoretical flow		11	15	18.5	22
M³/h	/min	Rated discharge pressure (MPa)
1.0	16.9	23.8	35	46.8	63.7	15
1.8	30	13.4	19.8	26.4	35.9	20
2.1	36	11.2	16.5	22	29.9	22
2.8	47	8.5	12.6	16.8	22.9	25
