High temperature pump SGW70

SGW70 series high pressure reciprocating pump can be used as high temperature and high pressure water power source. Used for large and small diameter pipe cleaning, ship cleaning, workpiece cleaning, rust removal, water corrosion cutting and other purposes. It can transport high temperature water (below 90 ℃), high temperature emulsion and liquid with chemical properties similar to water. The hydraulic end of the pump is equipped with a safety valve, throttle valve, self-contained system, adjustable throttle valve to adapt to different flow requirements. The power end of the pump is a bearing type transmission (between the crankshaft and the connecting rod). Gear grinding process manufacturing (straight teeth), low noise, small vibration, smooth transmission. The lubrication method adopts splash lubrication, which can run continuously for 24 hours, and the water cooling system is self-contained.

Keywords:

Classification:

High-pressure water-injection pump

wechat

E-mail:

Introduce

SGW70 series high pressure reciprocating pump can be used as high temperature and high pressure water power source. Used for large and small diameter pipe cleaning, ship cleaning, workpiece cleaning, rust removal, water corrosion cutting and other purposes. It can transport high temperature water (below 90 ℃), high temperature emulsion and liquid with chemical properties similar to water.
The hydraulic end of the pump is equipped with a safety valve, throttle valve, self-contained system, adjustable throttle valve to adapt to different flow requirements. The power end of the pump is a bearing type transmission (between the crankshaft and the connecting rod). Gear grinding process manufacturing (straight teeth), low noise, small vibration, smooth transmission. The lubrication method adopts splash lubrication, which can run continuously for 24 hours, and the water cooling system is self-contained.

For users to support a variety of cleaning machines, valves, high-pressure pipes, spray guns and so on.

According to customer demand supporting a variety of power sources.

Performance parameter table

Input shaft speed		1480r/min		Plunger stroke		84mm
theoretical flow		Motor power (kW)						Plunger Diameter mm
theoretical flow		22	37	45	55	75	90
M³/h	L/min	Rated discharge pressure (MPa)
1.0	16	67	//	//	//	//	//	15
1.7	29	37	62	75	//	/I	/I	20
2.7	45	24	40	49	60	81	//	25
3.9	65	16	28	35	42	57	70	30
4.5	75	14	26	32	39	53	62	32
5.4	90	12	21.3	26	32	44	50	35
7.0	117	9	16.5	20	25	34	40	40
9.0	148	7	12	16	19.5	26.5	30	45
